MAL213833102E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 6.3V AXIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet MAL213833102E3 Datasheet
-
ECAD Model
- Share
In Stock: 1,116
Can ship immediately
Pricing:
- 1$3.2
- 500$1.36868
- 1,000$1.19759
- 2,500$1.15482
- 5,000$1.11205
Quote It
Technical Details
- Series:138 AML
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):380mOhm @ 100Hz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:430 mA @ 100 Hz
- Ripple Current @ High Frequency:516 mA @ 10 kHz
- Impedance:300 mOhms
- Lead Spacing:-
- Size / Dimension:0.394" Dia x 0.709" L (10.00mm x 18.00mm)
- Height - Seated (Max):-
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Axial, Can
