EGXF350ELL821MJ25S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 35V RADIAL TH
- CategoryAluminum Electrolytic Capacitors
- Datasheet EGXF350ELL821MJ25S Datasheet
-
ECAD Model
- Share
In Stock: 795
Can ship immediately
Pricing:
- 1$1.56
- 10$1.22849
- 100$0.92144
- 500$0.69615
- 1,000$0.61425
- 2,500$0.57329
- 5,000$0.55692
Quote It
Technical Details
- Series:GXF
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):42mOhm @ 100kHz
- Lifetime @ Temp.:3000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.128 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
