URS1E332MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet URS1E332MHD Datasheet
-
ECAD Model
- Share
In Stock: 456
Can ship immediately
Pricing:
- 1$1.63
- 10$1.28678
- 100$0.96515
- 500$0.72926
- 1,000$0.64345
- 2,500$0.60055
- 5,000$0.58339
Quote It
Technical Details
- Series:URS
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.72 A @ 120 Hz
- Ripple Current @ High Frequency:1.978 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
