UCS2C101MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 160V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCS2C101MHD Datasheet
-
ECAD Model
- Share
In Stock: 385
Can ship immediately
Pricing:
- 1$1.66
- 10$1.31302
- 100$0.98482
- 500$0.74412
- 1,000$0.65657
- 2,500$0.61279
- 5,000$0.59528
Quote It
Technical Details
- Series:UCS
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:710 mA @ 120 Hz
- Ripple Current @ High Frequency:1.42 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
