EEE-TK1A222AM
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 10V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-TK1A222AM Datasheet
-
ECAD Model
- Share
In Stock: 502
Can ship immediately
Pricing:
- 1$2.74
- 125$1.6133
- 250$1.3828
- 625$1.22916
- 875$1.15234
- 1,250$1.07552
- 3,125$1.0371
- 6,250$0.99869
Quote It
Technical Details
- Series:TK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):80mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:825 mA @ 120 Hz
- Ripple Current @ High Frequency:1.1 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
