UBT1V102MHD8
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 35V THRUHOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBT1V102MHD8 Datasheet
-
ECAD Model
- Share
In Stock: 283
Can ship immediately
Pricing:
- 1$2.34
- 10$1.8939
- 100$1.44608
- 500$1.1018
- 1,000$0.96408
- 2,500$0.92965
- 5,000$0.89521
Quote It
Technical Details
- Series:UBT
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:1.347 A @ 120 Hz
- Ripple Current @ High Frequency:2.01 A @ 100 kHz
- Impedance:31 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
