EEU-ED2V820S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 82UF 20% 350V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-ED2V820S Datasheet
-
ECAD Model
- Share
In Stock: 612
Can ship immediately
Pricing:
- 1$2.45
- 10$1.97841
- 100$1.5106
- 500$1.15097
- 1,000$1.0071
- 2,500$0.97113
- 5,000$0.93517
Quote It
Technical Details
- Series:ED
- Package:Bulk
- Part Status:Active
- Capacitance:82 µF
- Tolerance:±20%
- Voltage - Rated:350 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:440 mA @ 120 Hz
- Ripple Current @ High Frequency:1.1 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
