ELZA160ELL332MK25S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELZA160ELL332MK25S Datasheet
-
ECAD Model
- Share
In Stock: 428
Can ship immediately
Pricing:
- 1$2.52
- 10$1.98451
- 100$1.48869
- 500$1.12483
- 1,000$0.99248
- 2,500$0.92632
- 5,000$0.89324
Quote It
Technical Details
- Series:LZA
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.763 A @ 120 Hz
- Ripple Current @ High Frequency:2.35 A @ 100 kHz
- Impedance:22 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
