109LBB016M2BC
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 16V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 109LBB016M2BC Datasheet
-
ECAD Model
- Share
In Stock: 476
Can ship immediately
Pricing:
- 1$2.55
- 10$2.06309
- 100$1.57565
- 500$1.20049
- 1,000$1.05043
- 2,500$1.01292
- 5,000$0.9754
Quote It
Technical Details
- Series:LBB
- Package:Bulk
- Part Status:Active
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):82.89mOhm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.77 A @ 120 Hz
- Ripple Current @ High Frequency:3.4625 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
