EEU-FC1H222E
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1H222E Datasheet
-
ECAD Model
- Share
In Stock: 335
Can ship immediately
Pricing:
- 1$2.61
- 10$2.10869
- 100$1.61003
- 500$1.22668
- 1,000$1.07334
- 2,500$1.04268
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.48 A @ 120 Hz
- Ripple Current @ High Frequency:3.1 A @ 100 kHz
- Impedance:23 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.476" (37.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
