UPS2A681MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS2A681MHD Datasheet
-
ECAD Model
- Share
In Stock: 321
Can ship immediately
Pricing:
- 1$2.76
- 10$2.22985
- 100$1.70303
- 500$1.29757
- 1,000$1.13537
- 2,500$1.10293
Quote It
Technical Details
- Series:UPS
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.001 A @ 120 Hz
- Ripple Current @ High Frequency:1.41 A @ 100 kHz
- Impedance:64 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.476" (37.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
