ESMR421VSN121MP25S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 120UF 20% 420V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet ESMR421VSN121MP25S Datasheet
-
ECAD Model
- Share
In Stock: 325
Can ship immediately
Pricing:
- 1$2.81
- 10$2.26408
- 100$1.76598
- 500$1.31317
- 1,000$1.2226
- 2,500$1.17732
- 5,000$1.15468
Quote It
Technical Details
- Series:SMR
- Package:Bulk
- Part Status:Active
- Capacitance:120 µF
- Tolerance:±20%
- Voltage - Rated:420 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.15 A @ 120 Hz
- Ripple Current @ High Frequency:1.6445 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.083" (27.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
