LGU2P221MELZ
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 220V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LGU2P221MELZ Datasheet
-
ECAD Model
- Share
In Stock: 350
Can ship immediately
Pricing:
- 1$2.84
- 10$2.2983
- 100$1.75501
- 500$1.33711
- 1,000$1.16997
- 2,500$1.13655
Quote It
Technical Details
- Series:LGU
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:220 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1 A @ 120 Hz
- Ripple Current @ High Frequency:1.5 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
