UAS2G390MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 39UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UAS2G390MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 239
Can ship immediately
Pricing:
- 1$2.96
- 10$2.39795
- 100$1.83117
- 500$1.39519
- 1,000$1.22079
- 2,500$1.17718
- 5,000$1.13359
Quote It
Technical Details
- Series:UAS
- Package:Bulk
- Part Status:Active
- Capacitance:39 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:255 mA @ 120 Hz
- Ripple Current @ High Frequency:408 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
