UCY2E181MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 180UF 20% 250V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCY2E181MHD Datasheet
-
ECAD Model
- Share
In Stock: 350
Can ship immediately
Pricing:
- 1$3.23
- 10$2.61566
- 100$1.99766
- 500$1.52203
- 1,000$1.33177
- 2,500$1.29372
Quote It
Technical Details
- Series:UCY
- Package:Bulk
- Part Status:Active
- Capacitance:180 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.11 A @ 120 Hz
- Ripple Current @ High Frequency:2.22 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.299" (33.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
