LGY1C183MELB30
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 18000UF 20% 16V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LGY1C183MELB30 Datasheet
-
ECAD Model
- Share
In Stock: 219
Can ship immediately
Pricing:
- 1$3.41
- 10$2.74915
- 100$2.14432
- 500$1.59451
- 1,000$1.49554
Quote It
Technical Details
- Series:LGY
- Package:Bulk
- Part Status:Active
- Capacitance:18000 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3 A @ 120 Hz
- Ripple Current @ High Frequency:3.45 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
