35USC15000MEFCSN25X45
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15000UF 20% 35V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 35USC15000MEFCSN25X45 Datasheet
-
ECAD Model
- Share
In Stock: 253
Can ship immediately
Pricing:
- 1$3.49
- 10$2.81487
- 100$2.19557
- 500$1.63263
- 1,000$1.52003
- 2,500$1.46373
- 5,000$1.43558
Quote It
Technical Details
- Series:USC
- Package:Bulk
- Part Status:Active
- Capacitance:15000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:4.8 A @ 120 Hz
- Ripple Current @ High Frequency:5.52 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.850" (47.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
