UBY2A561MHL
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- Description100V 560UF 20% HIGH TEMP LEADED
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBY2A561MHL Datasheet
-
ECAD Model
- Share
In Stock: 269
Can ship immediately
Pricing:
- 1$3.68
- 10$2.98036
- 100$2.27587
- 500$1.73396
- 1,000$1.51722
- 2,500$1.46303
- 5,000$1.40885
Quote It
Technical Details
- Series:UBY
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):27mOhm @ 100kHz
- Lifetime @ Temp.:3000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:2.295 A @ 120 Hz
- Ripple Current @ High Frequency:4.59 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
