EEU-ED2W470
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 450V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-ED2W470 Datasheet
-
ECAD Model
- Share
In Stock: 774
Can ship immediately
Pricing:
- 1$3.78
- 10$3.05732
- 100$2.33464
- 500$1.77874
- 1,000$1.5564
- 2,500$1.50081
- 5,000$1.44522
Quote It
Technical Details
- Series:ED
- Package:Bulk
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:400 mA @ 120 Hz
- Ripple Current @ High Frequency:1 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
