EGPD630ELL122ML30H
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EGPD630ELL122ML30H Datasheet
-
ECAD Model
- Share
In Stock: 658
Can ship immediately
Pricing:
- 1$4.34
- 10$3.50791
- 100$2.67897
- 500$2.04115
- 1,000$1.78602
- 2,500$1.72223
- 5,000$1.65843
Quote It
Technical Details
- Series:GPD
- Package:Bulk
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):34mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.316 A @ 120 Hz
- Ripple Current @ High Frequency:3.86 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
