LKG1H332MESBBK
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 50V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LKG1H332MESBBK Datasheet
-
ECAD Model
- Share
In Stock: 225
Can ship immediately
Pricing:
- 1$4.59
- 10$4.12911
- 100$3.11959
- 500$2.56908
- 1,000$2.49568
Quote It
Technical Details
- Series:LKG
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:2.8 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.181" (30.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
