LNT2E681MSE
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 250V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet LNT2E681MSE Datasheet
-
ECAD Model
- Share
In Stock: 210
Can ship immediately
Pricing:
- 1$19.17
- 10$18.2094
- 100$14.37624
- 500$13.03447
Quote It
Technical Details
- Series:LNT
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.4 A @ 120 Hz
- Ripple Current @ High Frequency:1.68 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.500" (12.70mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):3.268" (83.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
