LQR2G152MSEF
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 400V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet LQR2G152MSEF Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$40.38
- 10$38.14098
- 100$30.84916
Quote It
Technical Details
- Series:LQR
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:7.5 A @ 120 Hz
- Ripple Current @ High Frequency:10.5 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.866" (22.00mm)
- Size / Dimension:2.008" Dia (51.00mm)
- Height - Seated (Max):3.268" (83.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
