UPM2A390MPD6TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 39UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM2A390MPD6TD Datasheet
-
ECAD Model
- Share
In Stock: 1,053
Can ship immediately
Pricing:
- 1$0.72
- 500$0.25231
- 1,000$0.21447
- 2,500$0.20185
- 5,000$0.18923
- 12,500$0.17347
- 25,000$0.17032
- 50,000$0.164
Quote It
Technical Details
- Series:UPM
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:39 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:285 mA @ 120 Hz
- Ripple Current @ High Frequency:500 mA @ 10 kHz
- Impedance:360 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
