UPA1C681MPD6TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPA1C681MPD6TD Datasheet
-
ECAD Model
- Share
In Stock: 1,158
Can ship immediately
Pricing:
- 1$0.79
- 500$0.28677
- 1,000$0.24149
- 2,500$0.2264
- 5,000$0.2113
- 12,500$0.20074
- 25,000$0.19621
- 50,000$0.19244
Quote It
Technical Details
- Series:UPA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:675 mA @ 120 Hz
- Ripple Current @ High Frequency:900 mA @ 100 kHz
- Impedance:63 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
