UKT1E471MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKT1E471MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,017
Can ship immediately
Pricing:
- 1$0.9
- 500$0.29905
- 1,000$0.25183
- 2,500$0.23609
- 5,000$0.22035
- 12,500$0.20933
- 25,000$0.20461
- 50,000$0.20068
Quote It
Technical Details
- Series:UKT
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:380 mA @ 120 Hz
- Ripple Current @ High Frequency:570 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
