EEU-FS1H391LB
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 50V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FS1H391LB Datasheet
-
ECAD Model
- Share
In Stock: 827
Can ship immediately
Pricing:
- 1$1.07
- 500$0.41107
- 1,000$0.35398
- 2,500$0.33113
- 5,000$0.31401
- 12,500$0.29756
- 25,000$0.29118
Quote It
Technical Details
- Series:FS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.6125 A @ 120 Hz
- Ripple Current @ High Frequency:2.15 A @ 100 kHz
- Impedance:22 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
