UPJ0J222MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ0J222MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 580
Can ship immediately
Pricing:
- 1$1.05
- 250$0.43052
- 500$0.36902
- 750$0.33828
- 1,250$0.31777
- 2,500$0.29726
- 6,250$0.28189
- 12,500$0.26713
- 25,000$0.26139
Quote It
Technical Details
- Series:UPJ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.2 A @ 120 Hz
- Ripple Current @ High Frequency:1.34 A @ 10 kHz
- Impedance:78 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
