UBC1A221MNS1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 10V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBC1A221MNS1GS Datasheet
-
ECAD Model
- Share
In Stock: 657
Can ship immediately
Pricing:
- 1$1.27
- 500$0.51622
- 1,000$0.45548
- 2,500$0.42512
- 5,000$0.40994
- 12,500$0.38716
- 25,000$0.37957
Quote It
Technical Details
- Series:UBC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 150°C
- Operating Temperature:-40°C ~ 150°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:73.7 mA @ 120 Hz
- Ripple Current @ High Frequency:110 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.453" (11.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
