UPS1A472MHD1TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS1A472MHD1TN Datasheet
-
ECAD Model
- Share
In Stock: 754
Can ship immediately
Pricing:
- 1$1.16
- 250$0.52825
- 500$0.45278
- 750$0.41505
- 1,250$0.3899
- 2,500$0.36474
- 6,250$0.34587
- 12,500$0.32776
- 25,000$0.32071
Quote It
Technical Details
- Series:UPS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.653 A @ 120 Hz
- Ripple Current @ High Frequency:1.9 A @ 100 kHz
- Impedance:38 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
