UPM1H561MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1H561MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 605
Can ship immediately
Pricing:
- 1$1.27
- 250$0.55418
- 500$0.47105
- 750$0.44335
- 1,250$0.41564
- 2,500$0.38793
- 6,250$0.37407
- 12,500$0.35329
- 25,000$0.34636
Quote It
Technical Details
- Series:UPM
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.27 A @ 120 Hz
- Ripple Current @ High Frequency:1.55 A @ 10 kHz
- Impedance:44 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
