EEU-TP1V331B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-TP1V331B Datasheet
-
ECAD Model
- Share
In Stock: 737
Can ship immediately
Pricing:
- 1$1.67
- 500$0.68048
- 1,000$0.60041
- 2,500$0.56038
- 5,000$0.54038
- 12,500$0.51035
Quote It
Technical Details
- Series:TP
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.001 A @ 120 Hz
- Ripple Current @ High Frequency:1.1 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
