EEU-HD1E101
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-HD1E101 Datasheet
-
ECAD Model
- Share
In Stock: 727
Can ship immediately
Pricing:
- 1$0.85
- 10$0.5996
- 100$0.39444
- 500$0.29221
- 1,000$0.24839
- 2,500$0.23377
- 5,000$0.21916
Quote It
Technical Details
- Series:HD
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:130 mA @ 120 Hz
- Ripple Current @ High Frequency:195 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.500" (12.70mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
