UPJ1E561MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1E561MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 747
Can ship immediately
Pricing:
- 1$0.95
- 10$0.6959
- 100$0.4774
- 500$0.37796
- 1,000$0.31828
- 2,500$0.29839
- 5,000$0.2785
Quote It
Technical Details
- Series:UPJ
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:860 mA @ 120 Hz
- Ripple Current @ High Frequency:1.06 A @ 10 kHz
- Impedance:100 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
