6.3TLV2200M12.5X13.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 6.3TLV2200M12.5X13.5 Datasheet
-
ECAD Model
- Share
In Stock: 320
Can ship immediately
Pricing:
- 1$1.64
- 200$0.88419
- 400$0.78595
- 600$0.66804
- 1,000$0.58946
- 2,000$0.55016
- 5,000$0.53051
- 10,000$0.51087
- 20,000$0.50105
Quote It
Technical Details
- Series:TLV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:660 mA @ 120 Hz
- Ripple Current @ High Frequency:1.1 A @ 100 kHz
- Impedance:65 mOhms
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.512" L x 0.512" W (13.00mm x 13.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
