UHW1J271MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- Description63V 271UF 20% HIGH RELIA-LEADED
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHW1J271MPD Datasheet
-
ECAD Model
- Share
In Stock: 304
Can ship immediately
Pricing:
- 1$1.05
- 10$0.80021
- 100$0.57253
- 500$0.44325
- 1,000$0.38169
- 2,500$0.35707
- 5,000$0.3386
Quote It
Technical Details
- Series:UHW
- Package:Bulk
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:785 mA @ 120 Hz
- Ripple Current @ High Frequency:1.57 A @ 100 kHz
- Impedance:88 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
