EEU-FS1A822B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 8200UF 20% 10V T/H
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FS1A822B Datasheet
-
ECAD Model
- Share
In Stock: 1,114
Can ship immediately
Pricing:
- 1$2.03
- 250$0.97586
- 500$0.86742
- 750$0.8132
- 1,250$0.75899
- 2,500$0.73189
- 6,250$0.70478
- 12,500$0.67766
Quote It
Technical Details
- Series:FS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:8200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3.056 A @ 120 Hz
- Ripple Current @ High Frequency:3.82 A @ 100 kHz
- Impedance:14 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
