UPA1A682MHD1TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPA1A682MHD1TN Datasheet
-
ECAD Model
- Share
In Stock: 556
Can ship immediately
Pricing:
- 1$2.11
- 250$1.02813
- 500$0.87392
- 750$0.8225
- 1,250$0.77109
- 2,500$0.71969
- 6,250$0.69398
- 12,500$0.65543
Quote It
Technical Details
- Series:UPA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.346 A @ 120 Hz
- Ripple Current @ High Frequency:2.76 A @ 100 kHz
- Impedance:19 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
