UPM1E681MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1E681MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 609
Can ship immediately
Pricing:
- 1$1.13
- 10$0.88916
- 100$0.66693
- 500$0.50394
- 1,000$0.44464
- 2,500$0.415
- 5,000$0.40018
Quote It
Technical Details
- Series:UPM
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.05 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:55 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
