35SGV1000M16X21.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 35SGV1000M16X21.5 Datasheet
-
ECAD Model
- Share
In Stock: 329
Can ship immediately
Pricing:
- 1$2.55
- 75$1.71667
- 150$1.50207
- 375$1.28747
- 525$1.14442
- 750$1.07289
- 1,875$1.00137
- 3,750$0.9656
- 7,500$0.92984
Quote It
Technical Details
- Series:SGV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:750 mA @ 120 Hz
- Ripple Current @ High Frequency:900 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
