EEE-TK1E102AM
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-TK1E102AM Datasheet
-
ECAD Model
- Share
In Stock: 910
Can ship immediately
Pricing:
- 1$3.26
- 125$1.92265
- 250$1.64797
- 625$1.46488
- 875$1.37332
- 1,250$1.28175
- 3,125$1.23598
- 6,250$1.1902
Quote It
Technical Details
- Series:TK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):75mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:975 mA @ 120 Hz
- Ripple Current @ High Frequency:1.3 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
