B41888C5188M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1800UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41888C5188M000 Datasheet
-
ECAD Model
- Share
In Stock: 979
Can ship immediately
Pricing:
- 1$2.04
- 10$1.6539
- 100$1.26296
- 500$0.96223
- 1,000$0.84196
- 2,500$0.81189
- 5,000$0.78181
Quote It
Technical Details
- Series:B41888
- Package:Bulk
- Part Status:Active
- Capacitance:1800 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):29mOhm @ 10kHz
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2.53 A @ 100 kHz
- Impedance:26 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
