EEU-EB2C151
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 160V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-EB2C151 Datasheet
-
ECAD Model
- Share
In Stock: 306
Can ship immediately
Pricing:
- 1$2.07
- 10$1.63415
- 100$1.22544
- 500$0.92589
- 1,000$0.81696
- 2,500$0.76249
- 5,000$0.73527
Quote It
Technical Details
- Series:EB
- Package:Bulk
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:160 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:704 mA @ 120 Hz
- Ripple Current @ High Frequency:1.28 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.319" (33.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
