UCX1V561MNS1ZD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCX1V561MNS1ZD Datasheet
-
ECAD Model
- Share
In Stock: 327
Can ship immediately
Pricing:
- 1$2.23
- 70$1.57694
- 140$1.37979
- 560$1.05126
- 1,050$0.91987
- 2,520$0.88701
- 5,040$0.85416
Quote It
Technical Details
- Series:UCX
- Package:Tray
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):70mOhm
- Lifetime @ Temp.:2000 Hrs @ 135°C
- Operating Temperature:-40°C ~ 135°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:375 mA @ 120 Hz
- Ripple Current @ High Frequency:750 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:0.535" L x 0.535" W (13.60mm x 13.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
