EEU-FK0J562L
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 5600UF 20% 6.3V RAD TH
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 1,107
Can ship immediately
Pricing:
- 1$2.27
- 10$1.83905
- 100$1.40441
- 500$1.07006
- 1,000$0.9363
- 2,500$0.90955
Quote It
Technical Details
- Series:FK
- Package:Bulk
- Part Status:Active
- Capacitance:5600 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.176 A @ 120 Hz
- Ripple Current @ High Frequency:2.72 A @ 100 kHz
- Impedance:18 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
