URY1C222MRD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet URY1C222MRD Datasheet
-
ECAD Model
- Share
In Stock: 676
Can ship immediately
Pricing:
- 1$2.41
- 10$1.95464
- 100$1.49218
- 500$1.13691
- 1,000$0.9948
- 2,500$0.95926
- 5,000$0.92374
Quote It
Technical Details
- Series:URY
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1 A @ 120 Hz
- Ripple Current @ High Frequency:1.15 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.492" (12.50mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):0.571" (14.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
