EKZE6R3ELL682ML25S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKZE6R3ELL682ML25S Datasheet
-
ECAD Model
- Share
In Stock: 643
Can ship immediately
Pricing:
- 1$2.49
- 10$1.96206
- 100$1.47162
- 500$1.11183
- 1,000$0.98103
- 2,500$0.91563
- 5,000$0.88293
Quote It
Technical Details
- Series:KZE
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.941 A @ 120 Hz
- Ripple Current @ High Frequency:3.46 A @ 100 kHz
- Impedance:16 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
