UPA1A822MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 8200UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPA1A822MHD Datasheet
-
ECAD Model
- Share
In Stock: 289
Can ship immediately
Pricing:
- 1$2.92
- 10$2.35875
- 100$1.80117
- 500$1.37227
- 1,000$1.20074
- 2,500$1.15786
- 5,000$1.11497
Quote It
Technical Details
- Series:UPA
- Package:Bulk
- Part Status:Active
- Capacitance:8200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.389 A @ 120 Hz
- Ripple Current @ High Frequency:2.81 A @ 100 kHz
- Impedance:17 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.319" (33.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
