B43255A9686M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43255A9686M000 Datasheet
-
ECAD Model
- Share
In Stock: 432
Can ship immediately
Pricing:
- 1$3.13
- 10$2.57802
- 100$2.01737
- 500$1.58594
- 1,000$1.41339
- 2,500$1.37024
- 5,000$1.3271
Quote It
Technical Details
- Series:B43255
- Package:Bulk
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:480 mA @ 120 Hz
- Ripple Current @ High Frequency:744 mA @ 20 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.000" Dia (25.40mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
