688LBA025M2CC
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 25V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 688LBA025M2CC Datasheet
-
ECAD Model
- Share
In Stock: 741,678
Can ship immediately
Pricing:
- 1$3.17
- 10$2.56014
- 100$1.95522
- 500$1.48969
- 1,000$1.30348
- 2,500$1.25693
- 5,000$1.21037
Quote It
Technical Details
- Series:LBA
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):109.71mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.55 A @ 120 Hz
- Ripple Current @ High Frequency:3.1875 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
